Fiber optic transmittance detector

INGYI JY-QT02 Fiber Optic Transmittance Detector

🔹 Product Basic Info

Product Name: Fiber optic transmittance detector
Model: JY-QT02
Brand: JINGYI 景颐

🔹 Product Introduction

The fiber optic transmittance detector adopts advanced spectral measurement technology and can be used for full spectrum transmittance measurement of fiber optic guided beams. It is easy to operate, and by connecting the fiber optic to the two end interfaces of the sample chamber, the transmittance spectrum curve and values of the sample fiber at 380-1000nm can be displayed in real time.

🔹 Product Features

Features one: Real time display of transmittance full spectrum curve
Features two: The interface is clear, and the qualified judgment range can be customized and customized
Features three: Easy and fast operation, real-time testing
Features four: Accurate data and high cost-effectiveness
Features five: Stable broadband light source output, customizable light source wavelength range
Features six: Exportable test report

🔹 Product Parameters

Parameter	Specification
model	JY-QT02
spectral range	400-1000nm
Fiber optic connection port	Diameter 10mm
light source	High performance and long-life halogen lamp
Light source power	5W
Light source input voltage	220V
Usage temperature	5-80°C
computing system	Window7
network	wifi
Communication method	Wifi/USB interface
USB	USB3.0
Analysis software	Transmittance spectrum, color uniformity, end face image, supporting user-defined qualification judgment range
warranty	a year
