Double integrating sphere uniform light source - JFIOSWD

双积分球均匀光源 JY-JFIOSWD 产品介绍

Double integrating sphere uniform light source JY-JFIOSWD

Product Introduction The standard light source for testing weak light and high uniformity requirements adopts a dual integrating sphere design, with a uniformity output of over 99%. The light source intensity can be adjusted to 1x10⁻⁷lux weak light, which can be applied to highly sensitive microphotophotometers, image intensifiers, low light night vision devices, telescopic photometers, hyperspectral radiometers, and spectral radiometric calibration or correction.

Application Area Calibration of imaging systems and devices in the laboratory Film, digital camera, camera uniformity correction, spectral response characteristics Suitable for calibration of remote sensing instruments, CCD camera image arrays, and other detectors Biology, low light imaging, and quantitative measurement calibration, etc Uniform output for weak light, such as simulating starlight, moonlight, etc Used for calibrating low light measurement cameras, such as fluorescence measurement systems Uniformity correction of large and small aperture space remote sensing detection systems

Product Features Features one 99% high uniformity of light output Features two The area and position of the light outlet can be customized Features three Has excellent Lambertian characteristics Features four Brightness and color temperature can be customized Features five Customizable and adjustable brightness output Features six Customizable open flange

Product Parameters

model	JY-JFIOSWD
Spheroid diameter	200mm
Opening	40mm
Diameter of light source sphere	84mm
light source	Halogen lamp
uniformity	>99%
aperture	electric
illuminance	1x10⁻⁷-1x10³lux
Inner liner diffuse reflective material	PTFE
Coating process	spray
Coating spectral range	250-2500nm
support	contain
Temperature range for use	5℃~80℃
warranty	1year (Excluding self damage and consumables)
